The Dome Flying Theater is a 24-seat flying theater ride that simulates flight through a domed screen. It suits indoor parks, family entertainment centers, and mixed-use developments.
Figures below are the design values for this model. Site-specific engineering is confirmed per project.
The Dome Flying Theater is an overhead tour ride that gives riders the sensation of flight inside a domed projection environment. It is a movie-theme attraction suited to indoor parks, family entertainment centers, and mixed-use leisure developments. The ride combines gentle motion with visual media to create an immersive experience for a broad audience.
The ride is classified as Class A and uses an overhead tour configuration. It has four cabins that together carry 24 riders per cycle. The track height is 11m, and the overall equipment height is 11.5m. The ride moves at a low speed of 0.1m/s, which supports a controlled and comfortable experience. The structure is designed to the standards required by your market, confirmed per project. All engineering details are finalized during project planning to match local requirements.
The ride requires a footprint of 285㎡. The equipment height of 11.5m means the venue must have sufficient vertical clearance. The installed power capacity is 152kVA, and the power supply is 3N+PE 380V/220V 50Hz. Installation planning should account for the track height and the space needed for the four cabins. Site preparation and foundation design are confirmed per project based on local conditions.
The ride cycle is 600 seconds, which includes boarding, the flight experience, and disembarkation. With 24 riders per cycle, operators can plan hourly throughput based on this cycle time. The low operating speed of 0.1m/s reduces motion intensity, making the ride suitable for family audiences. Routine checks and maintenance should follow the manufacturer’s guidelines. Staff training and emergency procedures are part of the standard operating plan.
The questions park developers ask most about this ride — answered without the sales language.
The Dome Flying Theater has four cabins and carries a total of 24 riders per cycle. The cycle time is 600 seconds, including boarding and disembarkation, so hourly capacity depends on operational procedures and scheduling.
The ride requires a footprint of 285㎡ and an overall height of 11.5m. The track height is 11m. Venues must provide sufficient vertical clearance and floor space. Final installation requirements are confirmed per project based on site conditions.
The installed power capacity is 152kVA, and the ride operates on a 3N+PE 380V/220V 50Hz power supply. Electrical infrastructure should be planned accordingly. Local electrical standards and connection details are confirmed during project engineering.
Tell us about your project. Our engineering team will respond within 24 hours.
The same factory, quality process and certification documents stand behind every ride below — reviewed once here rather than repeated on each product page.
Design basis agreed against the standards your market requires, confirmed per project
Structure designed for a 20-year service life, stated in the contract for each project
Rigorous non-destructive testing at every production stage
Advanced surface treatment for extreme environments
Lightweight yet high-strength for wind resistance
Faster installation with premium visual finish
Integrated emergency release system for minimal downtime
Iconic skyline-defining structures
Maximum revenue efficiency with large cabin capacity
Thermostatic cabins for year-round comfortable riding
Multi-motor configuration for fault tolerance
Space-efficient layout for flexible site integration
Every ZhipaoRides product is engineered with redundant, fail-safe systems that meet or exceed international amusement ride safety standards. From electrical interlocks to structural redundancy, we leave nothing to chance.
Forced electrical interlocking prevents any unauthorized or unsafe startup. The system requires all safety conditions to be met before operation can begin, eliminating human-error risks.
Three independent door opening safeguards — mechanical lock, electrical sensor, and control system verification — eliminate passenger entrapment risk under all operating conditions.
Dual independent braking mechanisms with fail-safe engagement ensure controlled deceleration even in the event of primary system failure, meeting Class A ride standards.
Continuous sensor-based monitoring of vibration, temperature, and load distribution provides instant anomaly detection and automatic shutdown when parameters exceed safe thresholds.
Integrated auxiliary drive and manual release mechanisms enable safe passenger evacuation from any position, including during power outages or extreme weather conditions.
Non-destructive testing at every production stage — from raw material to final assembly — ensures structural integrity backed by 25-year design life certification.
Our safety systems undergo rigorous third-party testing and certification to meet or exceed GB 8408 (Chinese national standard) and EN 13814 (European standard) requirements. Each ride is equipped with multiple redundant safety mechanisms, ensuring passenger protection at all times. From the factory floor to the final installation site, our engineering team conducts comprehensive safety audits, load tests, and operational simulations before any ride enters service.
